HAProxy ALOHA 16.5 is now available, and we’re delighted to share that this release includes one of the cornerstone security features announced earlier this year—the new Bot Management Module. HAProxy ALOHA customers will also benefit from the new Network Management CLI, secure Wireguard VPN synchronization between appliances, updated root filesystem packages, and the features announced in open source HAProxy 3.0.
New to HAProxy ALOHA?
HAProxy ALOHA provides high-performance load balancing for TCP, UDP, QUIC, and HTTP-based applications; SSL processing; PacketShield DDoS protection; bot management; and a next-generation WAF. HAProxy ALOHA combines the performance, reliability, and flexibility of our open-source core (HAProxy – the most widely used software load balancer) with a convenient hardware or virtual appliance, an intuitive GUI, and world-class support. HAProxy ALOHA benefits from next-generation security layers powered by threat intelligence from HAProxy Edge and enhanced by machine learning.
What’s new?
HAProxy ALOHA 16.5 includes exclusive new features plus many of the features from the community version of HAProxy 3.0. For the full list of features, read the release notes for HAProxy ALOHA 16.5.
New in HAProxy ALOHA 16.5 are the following important features:
The new HAProxy Enterprise Bot Management Module provides fast, reliable, and flexible identification and categorization of bots attempting to access websites or applications, with 100% local processing for low latency and no external dependencies.
The new Network Management CLI (
netctl) allows customers to automate the management of network interfaces directly from the appliance itself. It operates as an abstraction layer that allows users to configure the network stack of the HAProxy ALOHA load balancer using a simple command-line tool.The new Wireguard VPN feature empowers customers to securely synchronize configurations between HAProxy ALOHA servers across the Internet or internal networks, making it easier to maintain consistency and manage configurations across appliances through an encrypted UDP tunnel that ensures data is protected when traveling between servers.
Updates to the root filesystem packages, including libraries, binaries, scripts, and all embedded components improve stability, security, and functionality.
We announced the release of HAProxy 3.0 in May 2024, which included improved simplicity, reliability, security, and flexibility. Many of the features from HAProxy 3.0 are now available in HAProxy ALOHA 16.5.
Some of the biggest community features include:
crt-store feature. Separates certificate storage from frontend use, simplifying and scaling SSL/TLS certificate management.
Enhanced HTTP/2 stack. Adds the option to limit and track glitchy HTTP/2 connections. HAProxy’s ability to handle the HTTP/2 CONTINUATION Flood demonstrates its resilience with this type of connection.
Machine-readable logs. Supports JSON and CBOR formats for easier log management and system interoperability.
Improved stick table performance. Lock contention reduced by sharing data across smaller, individual tables with separate locks.
Differentiated Services field support. Allows classification and traffic prioritization by setting the DS field on both frontend and backend connections via
set-fc-tosandset-bc-tosactions.Virtual ACL and map files. Enables in-memory ACL and map file representations using the
virt@prefix, avoiding filesystem searches.
We outline every community feature in detail in, “Reviewing Every New Feature in HAProxy 3.0”.
Ready to upgrade?
To start the upgrade procedure, visit the installation instructions for HAProxy ALOHA 16.5.
New bot management makes identifying bots and categorizing your traffic a breeze
Our customers have implemented some impressive bot management strategies using HAProxy ALOHA’s tools for traffic profiling, tracking, and filtering. Now, it’s even easier to use HAProxy ALOHA as a powerful alternative to a separate bot management solution. The new Bot Management Module provides fast, reliable, and flexible bot identification and categorization with low latency and deep integration with HAProxy ALOHA’s multi-layered security controls.
Why bot management?
From DoS attacks to content scraping, the risks from bot traffic are growing yearly. Failure to identify and block malicious bots could result in downtime, data theft, fraud, and more, affecting an organization’s reputation and revenue. Additionally, bot traffic can significantly increase resource use, which increases operational costs and could affect application performance for legitimate human users.
To combat the rising risks, we wanted to make effective bot management more accessible and more powerful. In HAProxy ALOHA 16.5, customers now have access to the new Bot Management Module, a new weapon in their arsenal against malicious bots.
What can you do with the new Bot Management Module?
HAProxy ALOHA’s new Bot Management Module works out-of-the-box to identify traffic accurately, categorizing it as human, suspicious, bot, verified crawler (search engines), or verified bot/tool/app (non-browser).
You can combine accurate bot identification with the other powerful layers in the security suite (including the next-generation HAProxy Enterprise WAF) to create customizable, high-performance, and low latency bot management and rate limiting strategies—from simple to advanced.
Why should you use the new Bot Management Module?
Three reasons:
Fast performance eliminates latency and ensures rapid bot identification and enforcement of bot management policies even under heavy load (e.g., DoS attack).
Reliable bot management with a simple architecture reduces complexity and keeps your data local and secure.
Flexible and customizable bot management shares intelligence with other powerful security layers for smarter, more holistic decision-making and enforcement.
For most users, we expect the simple answer to be: why wouldn’t you use it? 🙂 You can enable it in moments, and since it’s built into the firmware of HAProxy ALOHA—the plug-and-play hardware or virtual load balancer—it works quickly and efficiently even under heavy load.
But the real question for many customers is: why use this instead of one of the market-leading bot management solutions?
Unfortunately, bot management solutions often come with significant compromises (not even counting the extra cost).
Latency: solutions that pass requests through an additional layer, sometimes in a different network location, add latency (in addition to the often-quoted processing time) that affects the user experience.
Complexity: solutions that require a constant or frequent connection to the vendor’s cloud (for example, for automatic updates to the detection algorithm) introduce complexity and an additional point of failure, putting reliability and data privacy at risk.
Lack of integration: solutions without deep integration with other security layers, such as with the WAF and anomaly detection layers, make decisions with incomplete information and do not give users the flexibility to enhance and customize their bot management strategy.
HAProxy ALOHA’s new Bot Management Module uses reputational signals and scoring based on HAProxy Technologies’ security expertise, data science, and large real-world datasets to identify traffic accurately. Our data science team uses the threat intelligence data provided by HAProxy Edge to train our security models with machine learning, resulting in extremely accurate and efficient detection algorithms for bots and other threats – without relying on static lists and regex-based attack signatures.
Importantly, all the detection, processing, and enforcement is local to the appliance. It does not add additional layers to the request path and does not require an external connection. This minimizes latency, maximizes reliability, and gives you the flexibility to deploy anywhere you like—such as in air-gapped environments.
With deep integration with HAProxy ALOHA’s multi-layered security, you can customize your organization’s bot management to meet your unique needs and traffic profile. You can customize your enforcement policies with options including blocking, tarpitting, challenging, and rate limiting.
But how good is it at identifying bots? While this is hard to test in a benchmark scenario, in real-world deployments with early adopters on HAProxy Enterprise, the Bot Management Module helped a top eCommerce website handling 300,000 requests per second identify heavy amounts of suspicious traffic and avoid crippling outages. As much as 20% of traffic was identified as anomalous, which their previous system had accepted without raising any security concerns.
Now that the HAProxy Enterprise Bot Management Module has come to HAProxy ALOHA, our appliance customers can benefit from its fast, reliable, and flexible bot management capabilities to protect their business and reputation and reduce the resource cost of serving requests from unwanted bots.
New Network Management CLI puts more power in your hands
Previously, administrators could only configure the HAProxy ALOHA network stack using:
traditional command-line operations such as
ip routeandip ruleswithin the Linux command line—an effective approach that can be complex and require advanced networking knowledge; orthe HAProxy ALOHA Services tab—a simpler and more widely used method for our appliance customers.
While these approaches are effective, they focus exclusively on appliance-specific networking configurations. With modern environments increasingly blending hardware, software, cloud, on-premises systems, containers, and virtual machines, it became imperative that we introduce a more open and powerful networking alternative.
With the release of HAProxy ALOHA 16.5, we’ve introduced the new Network Management CLI (netctl), a first-of-its-kind feature in the HAProxy product stack. The Network Management CLI redefines how users configure their networks, harnessing the power of the Network API for an easier and more consistent approach directly from the appliance.
What are the benefits of the Network Management CLI
Netctl isn’t just a simple command-line utility—it's an interface that interacts directly with the Linux Network API, giving users access to a powerful networking suite. It centralizes and abstracts networking commands, like ip route, ip address, and ip link, into a single interface.
The Network Management CLI offers familiar and intuitive functionality for users accustomed to the Network Manager on Linux distributions. With netctl, you can program and manage the network environment directly from your HAProxy ALOHA appliance, making previously complex tasks, like creating link aggregations, defining VLANs, or managing IP routing, more accessible.
With the new Network Management CLI, HAProxy ALOHA users can:
Eliminate complexity by abstracting complex network tasks into simple CLI calls, enabling users to easily configure advanced setups such as link aggregation, virtual local area network (VLAN) over bridges, and virtual router redundancy protocol (VRRP) over VLANs.
Gain greater flexibility by providing a unified way to manage network settings without needing to switch between multiple tools or rely on extensive, manual command sequences.
Save time and avoid mistakes by streamlining the network setup process, reducing the manual effort required to implement complex setups, and minimizing the risk of human error.
The Network Management CLI demonstrates HAProxy Technologies’ commitment to providing extensive tools to its users over other offerings. It further enhances HAProxy ALOHA’s plug-and-play capabilities with a feature that now handles network configuration.
Enhanced reliability with updated network configuration scripts
In HAProxy ALOHA 16.5, we’ve also updated the network-scripts and config.rc to better support the Network API—which will manage the network stack of HAProxy ALOHA. This brings users more benefits beyond the Network Management CLI, including improved reliability and more efficient configuration.
With the updated network configuration scripts, users will benefit from:
Seamless rollback support by reverting to the previous configuration versions in the case of errors, ensuring continuity without requiring an appliance restart.
Streamlined VRRP configuration by automatically managing VRRP settings on interfaces, reducing complexity and minimizing misconfiguration.
Improved interface management by resolving issues such as deleting virtual interfaces.
New Wireguard VPN secures synchronization between appliances
In distributed environments, synchronizing configurations between appliances over a network can risk exposing sensitive data to potential security threats.
In HAProxy ALOHA 16.5, we’ve introduced Wireguard VPN, a powerful new feature that secures the way HAProxy ALOHA appliances in the same or different data centers communicate over a network.
Why Wireguard VPN?
When HAProxy ALOHA appliances operate in different data centers, synchronizing configuration can pose a risk if the appliances are not interconnected with a dedicated, private connection. While it’s possible to synchronize changes over the internet, this approach could lead to data being intercepted during transmission.
In HAProxy ALOHA 16.5, Wireguard VPN addresses this by providing a fully encrypted UDP tunnel of communication, ensuring that configuration data remains private and secure. Even in scenarios where data centers are interconnected, Wireguard VPN offers HAProxy ALOHA customers enhanced protection by encrypting all configuration data transmitted between the two appliances. This new secure tunnel ensures that bad actors monitoring your network cannot discover sensitive information about your HAProxy ALOHA deployment.
Enhanced stability and security with root filesystem updates
In HAProxy ALOHA 16.5, the root filesystem packages, including libraries, binaries, scripts, and all embedded components, have been updated to the latest version. This update inherits the maintenance of all the embedded open source projects, as well as security and functional fixes.
By updating the root filesystem, HAProxy ALOHA provides users with a more robust and reliable user experience.
Upgrade to HAProxy ALOHA 16.5
When you are ready to upgrade to HAProxy ALOHA 16.5, follow the link below.
